8500kg 40r/Min CNC Circular Saw Machine For Wood Cutting GKT608

1 Set
8500kg 40r/Min CNC Circular Saw Machine For Wood Cutting GKT608
Features Gallery Product Description Request A Quote
High Light:

40r/min cnc circular saw machine


8500kg cnc circular saw machine


40r/min wood circular saw machine

Basic Infomation
Place of Origin: China
Brand Name: HJ
Certification: ISO9001
Model Number: GKT608
Payment & Shipping Terms
Packaging Details: Plywood case or pallet
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Product Description

CNC Circular Cutting Saw Machine



The sawing strength can be 6b<1350N/mm2;Hardness within 40HRC of material difficult to cut


• Cutting sections free of burrs, stresses and cracks

• Digital automatic control, which can be integrated into the operation of the production line "turnkey" equipment

• Use vortex tube cooling technology and spray lubrication to cool the saw blade, which is green and environmentally friendly



  Parameters   unit   Specifications
  Saw blade specifications   mm   0830, 0965, <D1020
  Cutting material specification   mm   Φ70- Φ340.
  Cutting speed   r/mm   26, 32, 40, 48
  Feed speed   mm/min   0-500
  Quick return speed   mm/min   3000
  Table elevation   mm   914
  Main motor power   kw   55/67
  Machine net weight   kg   8500
  Machine tool floor space size   (excluding electric cabinet)   mm   About 5200 x2700x2260
